LKV104VW allows to create professional video wall displays with the LKV104VW 2×2 Video Wall Controller. Featuring 1 HDMI input and 4 HDMI outputs, it supports multiple display configurations including 2×2, 1×4, 4×1, and more. Ideal for digital signage, control rooms, security monitoring, retail displays, and commercial AV installations. Technical Features 1080p@60Hz 1920×1200 1 Input/4 Outputs Multiple Display Modes 3.5mm Audio Ouput RS-232 Control 180 degrees Image Rotation Plug and Play 8 Adjustable Display Modes Technical Details HDMI Input : 1x HDMI HDMI Output : 4x HDMI Compatibility: HDMI 1.4, HDCP 1.4 Resolutions : 1080P@60/50/30/25/24Hz, 720P@60/50Hz, 576P@50Hz, 480P@60Hz, 1920×1200@60Hz, 1680×1050@60Hz, 1600×900@60Hz, 1600×1200@60Hz, 1440×900@60Hz, 1400×1050@60Hz, 1366×768@60Hz, 1360×768@60Hz, 1280×1024@60Hz, 1280×960@60Hz, 1280×800@60Hz, 1280×768@60Hz, 1024×768@60Hz, 800×600@60Hz, 640×480@60Hz 3.5mm Output : PCM HDMI Output: PCM Mode: 1×1/2×1/1×2/2×2/3×1/1×3/4×1/1×4 Splice Settings: DIP Switch RS-232 (GND/ RxD/TxD): Default baud rate: 9600 Only when the dip switch is set to ‘111’ can the splicing mode be switched by RS-232 instruction Power Supply: DC5V/1A Power Consumption: ＜4W Working temperature: -20℃~60℃ Storage temperature: -30℃~70℃ Humidity: 0~90%RH（No condensation） Housing: Iron Weight: 381g Color: Black Dimensions: 160(L)*90(W)*20.6(H)mm Protection ESD protection 1a Contact discharge level 2 (±4KV) 1b Air discharge level 3 (±8KV) Implementation of the standard: IEC61000-4-2
